food grade 8um 10um 60um 100um 600um 1water filter polyester nylon monofilament filter screen mesh/disc/tube/bolti

food grade 8um 10um 200um 60um 100um 600um 1water filter polyester nylon monofilament filter screen mesh/disc/tube/bolting cloth

Mesh count: 10mesh (7T)-381mesh (165T)

Width : 0.6m to 3.65m
Length: 30m or 50m each roll, Customized size is available
Color : White

food grade 8um 10um 60um 100um 600um 1water filter polyester nylon monofilament filter screen mesh/disc/tube/bolti

Nylon mesh application:

Maishi Wire Mesh supply precision woven Nylon mesh. This can have plain weave or double warp structure and can be used in Filtration, Screening, Sifting or Milling applications from the production of filter bags, and screens to being injection moulded as special filter applications.
We can supply Nylon Mesh in many different sizes with a mesh opening of 32 to 1931 microns.

Nylon mesh features:.

1.100% Nylon Monofilament Material
2.Excellent Tear Resistance
3.Excellent Dimensional Stability
4.Higher Tension Strength & Break Point
5.Low Elongation

Nylon Filter Mesh Specification
Model	Mesh/cm	Mesh/inch	Aperture (μm)	Thread Dia. (μm)	Open Area (%)	Thickness (μm)	Theoretical Ink (cm3/m2)

36-100	36	90	178	100	41	195	86
40-100	40	100	150	100	36	192	95
44-100	44	110	127	100	31	175	105
48-80	48	120	128	80	38	150	73
56-60	56	142	120	60	44	110	48
59-60	59	150	110	60	42	98	50
64-60	64	160	100	60	38	120	55
72-50	72	183	89	50	41	90	44
80-50	80	203	75	50	36	93	48
88-40	88	224	74	40	42	65	34
96-40	96	244	64	40	38	76	37
100-40	100	254	60	40	36	78	39
104-40	104	264	56	40	34	79	40
120-40	120	305	43	40	27	80	46
Note:The above datas are theoretic,please reference the actual data if there is a difference!

Application

Widely used in filtering, textile printing and dyeing, printing plate, electronic printing, ceramics, glass printing and other industries.

widely used in filteration (wather, nut milk, flour, juices. soybean milk, oil, cheese, air purification, power coating filtering in industry etc. ), printing and dyeing, the industries of petroleum, chemical, metallurgy, cement, environmental dedusting etc.

Can be pieces, bags, discs, any size as you reque
