Brand Name : | GeZi |
Model Number : | GZ nylon screen mesh |
Certification : | ISO9001 |
Price : | Price discussion |
Payment Terms : | L/C, T/T, Western Union, MoneyGram,Paypal |
Supply Ability : | 300000 Meters per month |
Delivery Time : | within 7-15 days |
5/10/15 Micron Nylon Sieve Mesh Screen For Liquid Filtering White Color:
Material:
Nylon PA 6, nylon PA 6.6, polyethylene wire, etc.
Features:
Nylon mesh has the characteristics of high toughness, good
elasticity, corrosion resistance, oil resistance, water resistance,
wear resistance, high temperature resistance, weather resistance,
etc. It also has good insulation properties and low lubrication
coefficient.
Nylon Filter Mesh Specification | |||||||
Model | Mesh/cm | Mesh/inch | Aperture (μm) | Thread Dia. (μm) | Open Area (%) | Thickness (μm) | Theoretical Ink (cm3/m2) |
36-100 | 36 | 90 | 178 | 100 | 41 | 195 | 86 |
40-100 | 40 | 100 | 150 | 100 | 36 | 192 | 95 |
44-100 | 44 | 110 | 127 | 100 | 31 | 175 | 105 |
48-80 | 48 | 120 | 128 | 80 | 38 | 150 | 73 |
56-60 | 56 | 142 | 120 | 60 | 44 | 110 | 48 |
59-60 | 59 | 150 | 110 | 60 | 42 | 98 | 50 |
64-60 | 64 | 160 | 100 | 60 | 38 | 120 | 55 |
72-50 | 72 | 183 | 89 | 50 | 41 | 90 | 44 |
80-50 | 80 | 203 | 75 | 50 | 36 | 93 | 48 |
88-40 | 88 | 224 | 74 | 40 | 42 | 65 | 34 |
96-40 | 96 | 244 | 64 | 40 | 38 | 76 | 37 |
100-40 | 100 | 254 | 60 | 40 | 36 | 78 | 39 |
104-40 | 104 | 264 | 56 | 40 | 34 | 79 | 40 |
120-40 | 120 | 305 | 43 | 40 | 27 | 80 | 46 |
Note:The above datas are theoretic,please reference the actual data if there is a difference! |
Nylon screen mesh mainly Application:
Widely used in filtering, textile printing and dyeing, farming
mesh, wedding dressmaking, wallet bags screen mesh, rosin filter
bags making, nut milk filtration, celery filtration bags, flour
filtration etc.
widely used in filteration (wather, nut milk, flour, juices.
soybean milk, oil, cheese, air purification, power coating
filtering in industry etc. )
![]() |
